Manufacturer: Rockwell Automation
Brand: Allen-Bradley
Part number/Catalog number :MVI56-PDPS
Product Type: ControlL ogix PROFIBUS DP I/O secondary network interface
Rack type: Local or remote
The MV156-PDPS Slave Communication Network interface module is an interface device manufactured by InRAx to allow the ControlL ogix processor to interface with the PROFIBUS DP master device. MV156-
PDPS is supported by the PROFIBUS VO slave implementation, which greatly improves the speed and quality of data transfer between connected ControlL ogix processors and modules. The MV156-PDPS is available for user configuration
Set the data mapping function. Thanks to the DP operating port, the MV156-PDPS interface module is easy to use. For easier interface with PC, MV156-PDPS has - one configuration/debugging serial port, allowed
All sorts of things like status checking, monitoring, configuration, and troubleshooting. The serial cable for this purpose is supplied with the module when shipped.The MV156-PDPS has a rated voltage range between 5 and 24 volts DC. The MV156-PDPS has current ratings between 3 and 800 mA, and communication current ratings between 110 and 115,200 baud.The MV156-PDPS is required to operate at temperatures ranging from 32 to 140 degrees Fahrenheit. The pre-configured driver Settings for the MV156-PDPS can be downloaded from the PC and installed on the module. PROFIBUS DP Input and output of the slave stationLimited to 200 characters (without images) and 122 characters (with images). Input and output data blocks can be monitored separately and mapped onto the module's data memory for maximum flexibility and efficiency. rightFor data transmission between modules and processors, the MV156-PDPS uses ladder logic. The device offers local and remote rack options, as well as a configurable /0 backplane.
MVI56-PDPS is a Profibus DP Slave input/output module introduced by ProSoft Technology, which is used for communication with Profibus DP Master devices, can receive and send data, and realize data exchange with other devices.
The following are the main features and functions of the MVI56-PDPS module:
Modbus communication: The MVI56-PDPS module implements the Modbus TCP/IP and Modbus RTU/ASCII protocols, enabling it to communicate with Modbus devices that support these protocols.
Flexible data processing: The MVI56-PDPS module enables data mapping and data exchange between ControlLogix PLC and Modbus devices, enabling users to easily transfer data between the two systems.
Fast data transfer: This module enables efficient data exchange through fast data transfer and response time, suitable for real-time control and monitoring applications.
High reliability and stability: The MVI56-PDPS module usually has high reliability and stability to ensure stable data transmission and connection under various environmental conditions.
Compatible with Rockwell Automation's controllers: The MVI56-PDPS module is typically compatible with Rockwell Automation's controllers, such as the Allen-Bradley ControlLogix family, and can be seamlessly integrated into existing control systems.
In general, MVI56-PDPS is a very excellent Profibus DP communication module, with the advantages of high efficiency, stability, flexibility and reliability, suitable for various industrial automation control systems.
