The MVME2400 is a processor module produced by MOTOROLA, which belongs to the VME bus family. The module's features include multiple input Multiple output (MIMO) and high-speed data transmission, making it excellent in complex systems. For example, in applications such as modern large telescopes, the MVME2400 can be used as a key component for data processing and transmission.
The MVME2400 module usually has high-speed computing and control capabilities, and is suitable for a variety of application scenarios that require large amounts of data processing and control. It is also scalable and customizable, and can be configured and expanded according to specific needs.
In addition, the MVME2400 has high reliability and stability, which can maintain normal operation under various environmental conditions. It also has a low-power design that helps reduce energy consumption and cooling needs.
In summary, the MVME2400 is a high-performance, scalable, stable and reliable processor module for a variety of applications requiring large amounts of data processing and control.
The MVME2400 comes in a variety of speeds and memory sizes. The MVME2400 series can also be configured with a Scanbe front panel containing small outlet lugs, or an EEE front with airfoil ejection lugs
Board. There is sometimes a -1 or 3 at the end of the number to indicate the configuration of the Scanbe handle or wing handle.
PowerPC 750 32-bit microprocessor 32KB/32KB L1 cache 1MB Back-end L.2 cache 32MB to 512MB on-board ECC SDRAM up to 1MB of on-board firmware capacity or user-specified requirements
8MB on-board flash memory to meet user specific requirements On-board debug monitor with self-test diagnostics Two 32/64-bit PMC expansion slots with front panel and P2 |/ O64-bit PCI intercalated connector 8K
x 8 NVRAM and calendar clock with replaceable spare battery one asynchronous serial debug port four 32-bit timers, one 16-bit timer, one monitor clock 10/100Mb/s Ethernet interface level 4
Requester Level 7 interrupter and VMEbus Level 7 interrupt handler
The MVME2400 Series VME board offers the performance of the MOTOROLA PowerPlus architecture and can be fully customized to meet your application needs with two PC sandwich cards (PMC). flexibility
The MVME2400 provides an excellent foundation platform and is easy to customize for a variety of industry-specific applications. Utilize MOTOROLA's low-power, high-performance PowerPC 750 microprocessor, off-board
With Component Interconnect (PCI) bus peripherals, processor/memory bus to PCI bus bridge, and VME interface, the MVME2400 processor module integrates the best level of flexibility and performance into one
In the VME slot.
