The MVME5 100 series is the flagship of MOTOROLA's PowerPlus II VME architecture family
Supercomputing-level performance can be achieved in a single VMEbus slot. PowerPI
usI is based on ASI, an integrated PCI bridge memory controller designed by MOTOROLA Computer Group
C, improve memory performance to a new level, memory read bandwidth of 582MB/s, burst
The write bandwidth is 640MB/s.
The MVME5100 is part of MOTOROLA's family of embedded technologies and uses NXP MPC7410 or MPC750 microprocessors. It has a 32 KB/32 KB L1 cache and uses the Artesyn PowerPlus II architecture to support a full PCI throughput of 264MB/s without depleting the processor's memory. PowerPlus II is based on an integrated PCI bridge memory controller ASIC and can achieve a memory read bandwidth of 582mb /s and a burst write bandwidth of 640MB/s.
The MVME5100 is designed to meet the needs of OEM services and is optimized for specific applications. It is highly configurable and can be customized to meet specific needs. In addition, the MVME5100 has high reliability and stability, which can maintain normal operation under various environmental conditions.
It is important to note that MOTOROLA's products are generally more expensive and may add to the cost. In addition, although the MVME5100 has good flexibility and performance, some users may find it difficult to maintain and require professional technical support and repair services. In addition, due to the rapid replacement of MOTOROLA's products, older modules may have compatibility issues.
Details: MVME51 00 MOTOROLA PowerPlus II VME architecture single board computer
The MVME5100 series is the flagship of MOTOROLA's PowerPlus II VME architecture family, delivering supercompute-level performance in a single VMEbus slot. PowerPlus l is based on motorcycle Ferns
The integrated PC| Bridge memory controller ASIC designed by RA Computer Group takes memory performance to a new level with memory read bandwidth of 582MB/s and burst write bandwidth of 640MB/s. What's more,
The PowerPlus architecture supports a full PCI throughput of 264MB/s without depleting processor memory.
The extended temperature version of the MVME5100 series provides hardware and software compatible products to enhance existing MVME5100 products. The new version operates in a temperature range of -20° to 71°C, compared to the current version
Service versions are 0° to 55°C. This temperature range is beneficial for Oems who need to extend the operating temperature of their equipment.
The MVME5100 is designed to meet the needs of Oems serving the defense and aerospace, industrial automation, and medical segments.
■MPC7410, MPC750 or MPC755 microprocessor with 32KB/32KB L1 cache
Secondary background cache up to 2MB
100mhz front-end bus
Up to 512MB of on-board ECC sdram expandable to 1GB with optional RAM500 memory expansion module
17MB flash memory
■ Dual IEEE P1386.1 compatible with 32/64-bit PMC expansion slots
64-bit PCI expansion sandwich connectors allow up to four PMCS
■ Dual 16550 compatible with asynchronous serial ports
Dual 10BaseT/100BaseTX Ethernet
32KB NVRAM and clock, replaceable battery backup
Four 32-bit timers and one watch dog timer
■ On-board debugging monitor
■ Single VME slot, even fully configured with two PMC modules and two additional memory interlayers
