Warranty :12 months.
A 1.3GHz system-on-chip NXP MPC864xD with dual PowerPC e600 processor cores, dual integrated memory controllers, DMA engine, PCI Express interface, Ethernet and Ethernet
Local /O
● Board support for VxWorks, LynxOS and Linux
●2eSST VMEbus protocol, the transmission rate across VMEbus is 320MB/s
Up to 2GB DDR2 ECC memory, 128MB NOR flash and 2, 4 or 8GB NAND flash
● Four Gigabit Ethernet ports
USB 2.0 controller, eye integrated cost-effective peripherals (commercial temperature only
Dual 33/66/100MHz PMC-X sites, expanded with industry-standard modules that support processor PMCS
8x PCI Express extension connector with SMART EC XMCspan to support PMC-X and XMC extensions
● The MVME7216E is directly connected to the Rear Conversion Module (RTM) for /O routing through the rear of the VMEbus chassis
● Offers extended temperature range (-40°C to +71°C) and reinforced motherboards
peculiarity
Up to 1.3GHz system-on-chip Freescale MPC864xD with dual PowerPC e600 processor cores
●(4) Gigabit Ethernet port
● Up to 2GB DDR2 ECC memory
●128 NOR flash memory
●4gb or 8GB NAND flash
The Emerson/Ataxen MVME7100 series VMEbus single-board computers are among the first VMEbus products to use the system-on-chip MPC864xD processor: --, which is designed to complement the previous generation VME(especially
MPC74xx processor) VMEbus customers provide a path forward. System-on-chip implementations provide power/heat dissipation, reliability, and lifecycle benefits that alternative architectures typically do not.
The Emerson MVME7100 single-board Computer (SBC) helps original equipment manufacturers of industrial, medical, and defense/aerospace VMEbus platforms increase performance and functionality to gain a competitive advantage while still maintaining a competitive edge
Protect essential investments in VMEbus and related technologies. Customers can retain their VMEbus infrastructure (chassis, backplane, and other VMEbus and PMC boards) while improving performance and extending life weeks
Time. In addition, the long life cycle of Emerson computing products helps reduce development and support confusion caused by frequent product changes.
The combination of a faster processor and the 2eSST VMEbus interface significantly improves performance. New cost-effective peripherals can be easily integrated using the USB interface.
