Technical specification
This PCI-5421 is an arbitrary waveform generator device from the state instrument. The PCI-5421 device comes in three versions, with three options for on-board memory sizes. Part number 778692-01 has 8 MB board
The on-board memory part number 778692-02 has 32 MB of on-board memory, and the coarse part number 778692-03 has 256 MB of on-board memory. The device is used to generate arbitrary waveforms defined by the user. this
The PCI-5421 device can also generate standard sine, ramp, triangle, and square wave signals. To accurately generate the waveform PCI-5421 utilizes direct digital synthesis (DSS). The device can also be used for data streaming and advanced
Synchronize.
This PCI-5421 comes with an analog output channel with an SMB(jack) connector. The DAC resolution of the output channel is 16 bits. It is DC coupled. The output channel PCI-5421 device can
Combine waveforms in similar paths. This means that the device supports waveform summation. Therefore, the output terminals of different modules can be connected. This PCI-5421 waveform generator device has a maximum bandwidth of 43 MHz.
The device has a 7-pole elliptic filter.
This PCI-5421 waveform generator device has two two-way channels. Users can program these. These channels have SMB(jack) type connectors. The frequency range of these channels is DC to 105 megabits
Uh-oh. As input, these channels are used as trigger channels. The large input overload is -2 to +7 V voltage. These channels can also be used as the output of an event generator.
PCI-5421 is an arbitrary waveform generator from National Instruments (NI). It comes in three versions, with three options for on-board memory sizes:
Part number 778692-01 has 8 MB of onboard memory.
Part number 778692-02 has 32 MB of onboard memory.
Part number 778692-03 has 256 MB of onboard memory.
The PCI-5421 device is primarily used to generate user-defined arbitrary waveforms, but can also generate standard sine, slope, triangle, and square wave signals. It utilizes direct digital synthesis (DSS) technology to accurately generate waveforms, has high bandwidth (up to 43 MHz) and a 7-pole elliptical filter. The device also has an analog output channel and is equipped with an SMB (jack) connector, and the output channel has a DAC resolution of 16 bits and is DC coupled. This means that the device
supports waveform summation and can connect the output terminals of different modules.
