PFTL201C 10KN 3BSE007913R0010 ABB tension sensor
PFTL201C 10KN tension sensor English: Tension pick-up, tension sensor is tension
An instrument used to measure the tension value of a member during the control process. Used for pharmaceutical, strain gauge type expansion
The medium strain gauge and the compression strain gauge are connected together in a bridge mode when externally excited
The resistance value of the strain gauge will also change, and the amount of the change value of PFTL 201C 10KN will be proportional to the above
The amount of tension; The micro-displacement type is the displacement of the plate spring by applying the load of external force, and then through the difference
The tension is detected by the transformer, because the displacement of the plate spring is very small, about +200um
It is called a micro-displacement tension detector. PFTL201C 10KN In addition, the appearance structure and
Divided into: shaft table, through the shaft type, cantilever type, etc
The PFTL201C is a model of ABB tension controller with the following features:
High accuracy: Advanced control algorithm is used to ensure accurate tension control, which is suitable for applications requiring high tension accuracy.
Multi-channel control: Multiple tension devices or multiple winding systems can be controlled at the same time to improve production efficiency.
Adapt to harsh environment: can be installed in more harsh environment, such as high temperature, low temperature, strong magnetic environment.
High reliability: The use of high-quality electronic components and materials to ensure long-term stable operation.
Wide applicability: Suitable for tension control applications in various industrial production processes, such as textile, printing, packaging, wire and cable industries.
In addition, the PFTL201C tension controller is equipped with all the functions of the PFT series, including the PFT Series unique function keys and display that can display summation, differential or individual load cell signals. At the same time, it provides multi-language digital display and configuration keys for easy operation and maintenance. The PFTL201C also features high precision and reliability for tension control applications in a variety of industrial processes.
