The PXI-4132 is a programmable high precision signal source measurement unit (SMU). Features an isolated SMU channel providing four-quadrant output with remote (4-wire) detection and external protection. With its high measurement resolution and integrated multiple protections, the PXI-4132 is ideal for high-precision leak measurement applications in integrated circuits, stand-alone components, PCBS, and cables. On-board hardware sorting engine for high-speed I-V measurements for diodes, organic leds and other components. In addition, multiple PXI-4132 modules can be synchronized through the PXI backplane and high-speed I-V measurements can be performed on transistors and complex devices.
The PXIE-4132 is a high-precision source measurement unit (SMU) based on the PXIe bus. It has a ±100V output range and a current output of up to ±100mA, while also having a measurement sensitivity of up to 10pA. Its high-speed hardware trigger capability makes it suitable for a variety of applications, including high-speed I-V measurement and high-speed pulse train generation.
In addition, the PXY-4132 features four-quadrant operation, remote sensing connection, precise voltage control, high measurement resolution, and high measurement accuracy. It is suitable for high-precision leakage measurements of integrated circuits, discrete components, PCBS and cables, and can be used for high-speed I-V measurements of transistors and more complex devices.
Overall, the PXIe-4132 is a powerful and reliable source measurement unit for a variety of applications requiring high precision measurement. When choosing and using, users need to make trade-offs according to their own needs and budgets.
The PXIe-4132 programmable High precision signal source measurement unit is a device for generating and measuring a wide range of signals with a high degree of flexibility and accuracy. It usually has the following features and functions:
Programmability: The user can set the output parameters of the signal source through programming, such as frequency, amplitude, phase, etc. This allows it to generate a variety of custom signals to meet different test needs.
High precision: PXIe-4132 has high precision signal generation and measurement capabilities, providing accurate signal output and accurate measurement results.
Multi-function: It can not only generate various types of signals, such as sine wave, square wave, pulse wave, etc., but also measure the parameters of the signal, such as frequency, amplitude, distortion degree, etc.
The PXIe-4132 has a wide frequency range: it can cover a wide frequency range, from low frequency to high frequency, to meet the needs of different application areas.
Signal conditioning: Provide signal conditioning functions, such as filtering, amplification, attenuation, etc., in order to pre-process or post-process the signal.
Interface and communication: The PXY-4132 has a variety of interface options such as USB, Ethernet, GPIB, etc., to connect and communicate with computers, other devices, or test systems.
Software control: Usually equipped with corresponding software tools for programming, controlling and analyzing the functions of the signal source measurement unit.
PXIe-4132 programmable high precision signal source measurement unit is widely used in electronic testing, communication system testing, instrument calibration and other fields. It can help users generate and analyze various signals to evaluate and verify the performance of the system. The specific application scenarios and functions depend on the model of the measuring unit and the needs of the user.
