Scxi-1104c SCXI voltage input module SCXI-1104C
This is National Instruments SCXI-1104C(Part number :776572-04C, 18308)
7H-05) The voltage input module has 32 differential channels for signaling higher voltage signals
Conditioning. This model is equipped with a 10 kHz cut-off frequency filter. If users want to take advantage of nickel S
CXI-1104C In ribbon cable multi-chassis SCXI systems, they need to use SCXI-1
346 + case adapters. If the user chooses not to automatically detect the SCXI module, it must be single
Add a module alone. This can be done by following the instructions in the user manual.
When using the software, the user can connect pins 1, 2, 4 or 19 to the analog ground of the voltage input module. The customer can use the | pin connected to the analog ground as the SCXI- ground connection point for the analog power supply
1104C. An important fact to keep in mind is that the nickel SCX1-1 104C analog output has no overvoltage protection. Therefore, applying an external voltage to this output will damage the module. Although the analog output has a short circuit protection
Protect. The recommended preheating time for the device is 20 minutes and the operating temperature is 0 to 50°c.
The National Instruments SCXI-1104C can calibrate the module by applying a precise voltage to the channel input and/or grounding the channel input. The module should be recalibrated at least once a year, or as specified
Recalibrate at any time when operating outside the temperature range. This NI SCXI-1104C voltage input module can be calibrated with a multi-range 8.5 digital multimeter. The device has a cut-off frequency of 10 kHz. When a user uses
When the NI software completes the measurement, the driver automatically adjusts the measured voltage to the correct value using a calibration constant.
NI-DAQ version 6.5.1(or later) is the software driver SCXI-1104C used to run it. To install the driver, you need an application development environment, such as L abVIEW,
BridgeVIEW, LabWin
The functions of SCXI-1104C include:
Signal interface: The module provides multiple signal interfaces that allow sensors, signal sources and measuring devices to be connected to the system.
Data acquisition: It converts analog signals collected from sensors and measuring devices into digital signals for subsequent processing and analysis.
Analog signal conditioning: Modules may include some analog signal conditioning functions, such as amplification, filtering, and amplification.
Encoder input: The SCXI-1104C module has a specialized interface for connecting the encoder sensor and can read and process the pulse signal from the encoder.
Laboratory measurement: Usually used in the laboratory to carry out various physical experiments and measurements.
