SCXI-1304 | AC-DC coupling terminal | Can provide more accurate measurements

Name: SCXI-1304 | AC-DC coupling terminal | Can provide more accurate measurements
Brand: xiongba-dcs
SKU: SCXI-1304
Availability: InStock
Rating: 5 (1 reviews)

No.SCXI-1304

Brand: NI
Model: SCXI-1304
Product type: AC-DC coupling terminal
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months

GET A QUOTE

Add to Quote List View Quote List

Desciption

SCXI-1304 Product description:
Brand: NI
Model: SCXI-1304
Product type: AC-DC coupling terminal
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months

SCXI-1304 features:

The SCXI-1304 (Part number: 777687-04) is the terminal of the National Instruments SCXI series. The AC/DC coupled terminals can be used with SCXI-1140, SCXI-1141/1142/1143, SCXI-1120/D and SCXI-1125 modules. In addition to AC/DC coupling, this model has a BNC connector and signal ground reference that can be configured for each channel. The NI SCXI-1304 has 22 screw terminals for easy signal connection. Users can connect signals to eight module inputs using eight pairs of screw terminals and analog grounding to modules using one pair of screw terminals. The other four screw terminals have access to the module's digital ground and digital signals. For SCXI-1140, these signals are HOLDTRIG. However, for SCXI-1141/1142/1143, these signals are OUTCLK and EXTCLK.

Application areas of SCXI-1304:
SCXI-1304 is widely used in laboratory testing, data acquisition, sensor measurement, automation control and other fields. They can be used with other modular measurement system modules, such as data acquisition modules, signal conditioning modules, etc. The sampling rate determines how quickly the module can acquire data from the input signal. Resolution refers to the smallest unit of signal change that a module can recognize, and higher resolution can provide more accurate measurements.
