Advantages:
Increase productivity MQ controllers are as fast as MD Plus controllers and offer the same configurable memory as MD Plus controllers. Ethernet ports are full-duplex,
Maximum throughput of 100MB/ s. The result is lower CPU utilization and higher control policy capacity.
Self-addressing. The DeltaV controller is unique in its ability to automatically identify itself in the DeltaV control network. When the controller is powered on, it automatically assigns a unique
Address one no dip switch, no configuration one just plug in
Play!
Position yourself. The physical location of the controller is easy to find. Leds on the surface of the controller can flash, providing strong visual cues.
Automatic I0 detection. The controller can identify all l/0 interface channels located on the child. Once the l/0 interface is inserted, the controller knows the current managed by the l/0 interface
General characteristics of field equipment. This reduces configuration related worthless engineering.
Connect to electronic wiring and wireless I0. Starting with DeltaV v14.3, CHARM and wireless I/O cards connected via CHARM I/O cards (CIOC) and WIOC can be combined
Wireless devices are assigned to MQ controllers. This makes it easier to add 1I0 to an existing controller by simply adding CIOC and or WIOC to the DeltaV area control network
It's easier all the time.
Easy to use full control. The controller manages all control activities for the l/O interface channel. It also manages all communication functions of the communication network. Timestamps, alerts, and trend objects are also available
Manage within the controller. The controller executes all control strategies at an execution rate of up to every 100 seconds.
Data protection. All online changes made to the control parameters are automatically stored for later upload to the engineering database. This way, the system always keeps all changes that have been made online
Complete record of the data.
Advanced operation. The MQ controller handles DeltaV batch processing options as well as advanced control functions.
Transparent data transmission. The controller is capable of transferring intelligent HART⑧ information from field devices to any workstation node in the control network. This means you can take advantage of asset management solutions
Applications such as AMS Device Manager enable you to remotely manage HART information contained in devices equipped with HART or FOUNDATION fieldbuses.
Prepare for the future. As your system grows, you can extend the software license to increase the number of device signal tags (DST) assigned to DeltaV controllers. From 50
It started with 750 DST. The complexity of control strategy and the scanning rate of control module determine the overall controller performance and application scale. Redundant controllers can be added to come online
Back up the MQ controller. The standby controller is automatically online, and the transition is smooth. For more information, see the 1I0 Redundancy Product Data Sheet.
Install. This plug-and-play system architecture provides modular system expansion through a single controller, and groups can be installed in Class 1, Div 2, or ATEX Zone 2 environments.
For more information, see the System Power Supply and I/0 subsystem Carrier Product data sheet.
