Brand Siemens
Model number 6AV2124-0MC01-0AX0
Type, touch screen
Siemens Touch screen HMI, TFT display type, 12MB onboard memory -SIMATIC TP1200 Series -6AV2124-0MCO1-0AXO
Control industrial machinery with this touchscreen HMI from Siemens. Automated processes can be visualized and managed through interactive TFT displays to keep the system running efficiently. 1280 x80O high resolution, can clearly display details for maximum readability. There is an alphanumeric keyboard on the screen, which is easy to adjust as needed. The device offers multiple interface options, including USB2.0, USB MiniB, and a combined RS 422/485 port for flexibility. Such touch screens are commonly used in traffic control and food processing applications.
Characteristics and advantages
· Can be installed horizontally or vertically depending on your location
· The PROFlenergy function automatically turns off at static to save energy -LED indicator for easy check of Ethernet connection status
.Wide operating temperature range from 0°C to +40° C, withstands harsh conditions.32 language Settings, widely used in diverse workplaces
Is this product waterproof?
Yes, this screen has an IP65 rating to protect against high pressure jets of water from all directions.
Siemens Operating panel 62124-OMCO1-OAXO6AV2124-OMCO1-OAXO
SIMATIC HMI TP1200 Comfort, Smart panel, touch operation, 12 "widescreen TFT display, 16 million colors, PROFINET interface, MPVPROFIBUS-DP interface, 12MByte project mode memory,Windows CE6.0 (Microsoft-Support includes update Settings) can be project mode version WinCC Smart version 11
PLC model selection steps and principles
With the development of PLC technology, there are more and more types of PLC products. Different types of PLC, its structural form, performance, capacity, instruction system, programming methods, prices, etc., are also different, and the applicable occasions also have their own focus. Therefore, the reasonable selection of PLC is of great significance for improving the technical and economic indicators of PLC control system.
The selection of PLC is mainly considered from the PLC model, capacity, IO module, power module, special function module, communication networking capability and other aspects.
