Brand: Siemens
Model: 6GK5202-2BB00-2BA3
Type: programmable logic controller
6GK5202-2BB00-2BA3 is a product of the Siemens brand.
Siemens is the world's leading electronic and electrical engineering company, founded in 1847, headquartered in Munich, Germany. The 6GK5202-2BB00-2BA3 is a Siemens S7-300 series programmable controller with 100 megabit ports.
The 6GK5202-2BB00-2BA3 photoelectric conversion module is one of the main components of the Siemens Industrial Automation product family for the control and monitoring of industrial production processes.
The module is usually installed in the PLC (Programmable logic controller) system and is the core of the PLC system. 6GK5202-2BB00-2BA3
Photoelectric conversion modules are available in many different models and specifications to meet different application needs.
The Programmable Logic Controller (PLC) is a digital electronic device with a microprocessor, a digital logic controller for automatic control, which can load control instructions into the memory at any time for storage and operation. Programmable controller by the internal CPU, instruction and data memory, input and output units, power modules, digital analog and other units modular composition, can receive (input) and send (output) a variety of types of electrical or electronic signals, and use them to control or supervise almost all kinds of mechanical and electrical systems.
| Parameter |
Value |
| Product Model |
Siemens 6GK5202-2BB00-2BA3 |
| Manufacturer |
Siemens |
| Product Type |
Industrial Automation Control Module (Ethernet Switch Module) |
| Power |
24V DC ±10%, 6W Maximum Consumption |
| Communication / Protocol |
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, PROFINET IO, Modbus TCP |
| Operating Temperature |
-10°C – 60°C (14°F – 140°F), 5% – 95% RH (Non-Condensing) |
| Mounting |
DIN Rail Mount (35mm Standard) |
| Dimensions (HxWxD) |
120mm x 45mm x 115mm (4.7" x 1.8" x 4.5") |
| Weight |
420g (0.93 lbs) |
| Typical Interfaces |
8 x 10/100/1000 Mbps RJ45 Ports, 2 x SFP Slots (for Fiber Optic Expansion) |
| Compliance |
IEC 61010-1, CE, UL 508, RoHS 3.0, ISO 9001 |
The advantages of 6GK5202-2BB00-2BA3 photoelectric conversion module are as follows:
Fast transmission speed: can provide 100 Mbit transmission rate.
Long transmission distance: single-mode fiber can be transmitted 30 kilometers, multi-mode fiber can be transmitted 3 kilometers.
Stable performance: with high anti-interference ability and stability.
Strong compatibility: can be used with Siemens S7-300 series PLC.
Convenient and flexible: Modular design, easy installation and maintenance
