SM23165D | M connector | Provides the perfect integrated server

Brand: MOOG
Model: SM23165D
Product Type:M connector
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months

Moog Animatics' Class 5 SmartMotor™ with M-type connectors offers optional IP65 and IP67 ratings for NEMA 23 and 34 frame sizes. This series of harsh environment grade M-type intelligent motors combines the quality of an integrated server with advanced motion control functions along with an IP grade. With an IP65 rating, SmartMotors is both completely dust resistant and prevents liquids from entering from any Angle, with no harmful effects on the electrical housing. IP67 rated SmartMotors can be submerged in water or other harmless liquids up to a depth of 1 meter for up to 30 minutes. As a result, conditions of high humidity and condensation are no longer a problem. The IP-class models provide the perfect integrated server for food and beverage manufacturing and packaging, harsh outdoor conditions, and any humid environment.

Parameters:
Specification motor
Continuous torque: 0.28Nm
Peak torque: 0.45Nm
No load speed: 10'400 RPM @48VDC
Peak power @6500 RPM: 181W
Encoder resolution: 4000incr./rev.
Rotor inertia: 0.6991 *10-5 Kg-m 2
Voltage constant: 4.45V /kRPM
Motor weight: 0.45kg
Axle diameter: 6.35mm
Shaft, maximum radial load: 3.18kg
Shatt, maximum axial load: 1.36kg

Performance parameters:
Continuous stall torque ratings of.15 to 77 Nm (1.3 to 681 lb-in) are available.
Available in a variety of sizes, nominal torques range from 2 Nm to 99 Nm and peak torques from 11 Nm to 2,89 Nm.
Structural features:
Designed with permanent magnet brushless servo motor, with high performance and high acceleration.
The modular construction enables it to offer a wide range of shaft and flange options.
Configuration options:
Special windings can be combined to optimize performance.
It can be equipped with rotary transformers, different types of encoders and brakes.

Application field:
Automotive Manufacturing and Testing:
In the automotive manufacturing and testing process, precise servo control is required to ensure the accurate installation and testing of components. The high precision and dynamic performance of the SM23165D series motors make them ideal for these applications.
Modular design and flexibility:
The modular design of the SM23165D series motors allows for easy integration with other systems and equipment. This flexibility allows it to find the right solution in a variety of complex application scenarios.
