The 16 channel relay module is a full height module that provides 16 relay outputs. any
The number of 1 6 channel relay modules can be placed in the right slot of any rack interface module
Groove. Each of the 16-channel output relay modules can be programmed independently to perform what is required
Voting logic.
Each relay used on the 16-channel relay module includes an "alarm drive logic.
Volume ". Programming for alarm driver logic uses AND and or logic, and can be made
Use alarm input (alarm and danger status), abnormal or from any monitor in the rack
Channel or any combination of monitoring channels. The user uses the 3500 framework configuration software for this alarm drive
Dynamic programming to meet the specific needs of the application.
3500/33 Bently Nevada technical specifications
The 16 channel relay module is a full height module that provides 16 relay outputs. You can place any number of 16- on the right of any slot in the channel relay module transient data interface module. 16-way
Each output of the channel relay module can be independently programmed to perform voting logic. Each relay in the module includes alarm drive logic. Alarm driver logic can be programmed using AND and or logic and
Use the following :n Alarm inputs (alarm and danger status) are not good n separate measurement variables from any monitor channel or any combination of monitor channels in the rack You can use 3500 frame pairs
|
Label
|
Specification
|
|
Model Number
|
3500/33
|
|
Brand
|
Triconex (Schneider Electric)
|
|
Type
|
16-Channel Relay Output Module
|
|
Input Voltage
|
24V DC (18V – 32V DC, typical)
|
|
Operating Temp
|
-40°C – +70°C (-40°F – 158°F)
|
|
Communication Method
|
Backplane integration with 3500 system
|
|
Mounting
|
3500 Series Instrument Rack (1-slot width)
|
|
Weight
|
1.2 lbs (0.54 kg)
|
|
Certifications
|
CE, UL, CSA, SIL 3, IECEx
|
|
Dimensions
|
12.6 cm x 11.5 cm x 3.4 cm (4.96” x 4.53” x 1.34”)
|
|
IP Rating
|
IP20 (rack-mounted, front panel)
|
|
Protocols Supported
|
Triconex System Bus, Tristation 1100/1102 compatible
|
|
Relay Configuration
|
16 independent SPDT relays (10A @ 250V AC/30V DC)
|
|
Diagnostic Coverage
|
Channel-level fault detection with LED indicators
|
Alarm driver performs programming configuration software. n The 16-channel relay module requires a 3500 frame configuration, version 3.3 or later. 1 6-channel relay module requires 3500 data acquisition software, 2.40 or higher
Version. The 16-channel relay module requires 3500 data display software, version = 1.40 or higher. n When ordering in multiples of the certification option (02), the 3500 monitor is certified to Zone 2 standards, including ATEX and
North America. The N2-zone standard specifies increased spacing requirements at higher voltages. The 16 channel relay module does not meet these spacing requirements. As a result, module approval options with multiples - starting orders are limited to a lower level
The voltage is higher than those with other approved options. n Using a higher voltage violates the Hazardous Area Certificate Multiple approval option related to the following. The North American Part 2 Standard associated with the CSA-only approval option (-01) has been downgraded to 30Vrms to meet the 61010-1 type test requirements. n If the 1 6-channel relay module is a functional safety (SIL) system, the functional safety certificate requires limited voltage. Higher voltages will not be allowed for functional safety (SIL) systems.
