The Triconex 3500/42M is a Bentley mechanical monitoring system that belongs to the 3500 series of cards. It has a variety of functions and features, including high reliability, high precision, high stability and so on. It is commonly used in various industrial control and automation systems to monitor the operating status and safety status of mechanical equipment.
The Triconex 3500/42M card can be connected and communicated with mechanical equipment through a variety of sensors and actuators, enabling real-time monitoring and data acquisition of equipment status. It can also be combined and linked with other 3500 series cards to achieve more complex and efficient control and monitoring functions.
Triconex 3500/42M cards are typically manufactured and sold by Bentley or other authorized suppliers. It is suitable for various industrial fields, such as petroleum, chemical, electric power, metallurgy, etc., and can meet the needs of different customers.
In summary, the Triconex 3500/42M is an efficient, reliable and flexible mechanical monitoring system for critical control applications in a wide range of industrial processes. It is one of the ideal choices for industrial automation and safety control.
Technical Note: 3500/42M 140734-02 Proximitor seismic monitoring module can be used on each pass
The channel programmed 3500/42M is the Proximitor seismic monitoring component developed publicly by Bentley Nevada. This is a four-channel monitor with short range and seismic sensor inputs. It compares the adjusted signal with a user-programmable alarm and adjusts the signal to produce vibration and position readings. The 3500 frame configuration software can be used to program each channel to monitor and report radial vibration, thrust level
Set, reinforcement, acceleration, differential expansion, eccentricity, speed and other parameters.
3500/42M function monitoring channels are set up in pairs and can perform up to two specified functions simultaneously. For example, channels 1 and 2 May perform one function, while channels 3 and 4 perform another or the same function.
The Proximitor seismic monitor protects the machine by comparing monitoring parameters and selected alarm Settings in real time, triggering an alarm. It informs operators and maintainers I of important machine information.
Depending on the configuration, each channel typically adjusts its input signal to produce a -group static value. You can create an alarm set point for any current static value, and you can create a hazard for any two of them
Set point.
Use the framework configuration software to set an alert level for any value measured by the monitor and a danger set point for any two values measured by the monitor. For each measurement, the alarm can be set to full scale
0-100%. When the full scale range exceeds the sensor range, the set value is limited by the sensor range.
3500/42M technical features
input
Accept - signals to four proximity sensors, acceleration sensors, or speed sensors.
Power consumption 7.7 watts.
exportation
When the monitor module is working normally, the OK LED lights up.
When the seismic monitoring module is connected to other modules in the 3500 frame, the TX/RX LED lights up.
If the seismic monitor is in bypass mode, the bypass LED lights up.
Buffer sensors: Each channel has its own coaxial connector on the front of the display. Each connector has built-in short-circuit protection.
550 ohms output impedance
Shaft power supply - 24 volts DC
Resolution :0.3662A bits
Sensor power supply -24 volts DC
The impedance of the absolute output is 300 ohms
Signal processing
Temperature :25 degrees Celsius
