Technical specifications for IC660CBB902
Brand GE Fanuc
Series Genius I-O
Part number IC660CBB902
Description 6 series PLC bus controllers
Application series 6 PLC system
Configure CPU or handheld display
Maximum I/O capacity 31 I/O devices
Phase type B
The baud rate is optional except the standard rate of 153.6 KB
Maximum connection distance 2000 feet
Compatible I/O blocks feature Genius I/O modules with more than 64 input/output bits
Built-in diagnostics Yes
Location CPU slot, remote I/O rack, or large-capacity I/O rack
GE Fanuc IC660CBB902 Series 6 Bus controllers are Series 6 PLC bus controllers. The device connects the 6 series PLC to the Genius I/O serial bus. The Genius I/O serial bus can accommodate up to 31 I/O devices on the bus, including Genius I/O modules, interface modules, and handheld displays. It also supports a variety of Genius I/O blocks that can be used for configuration communication between the 6 Series PLC and the Genius I/O devices connected on the bus. The IC660CBB902 bus controller belongs to the Phase B Enhanced Bus controller family. It is suitable for buses using any baud rate other than the standard rate of 153.6 Kilobaud and with a maximum connection distance of less than 2000 feet. The IC660CBB902 bus controller is also compatible with buses with resistance temperature detector (RTD) blocks or Genius I/O blocks with more than 64 I/O bits, Series 6 PLC systems with CPU-to-CPU communication, and systems with bus redundancy.
The GE Fanuc IC660CBB902 bus controller comes with a built-in diagnostic function that automatically sends diagnostic reports from the Genius I/O block on the bus to the CPU. The IC660CBB902 bus controller can be installed in any I/O slot on a Series 6 CPU, in a regular or high-capacity I/O rack, or in a remote I/O rack (although this is not recommended). The IC660CBB902 bus controller has 2 LED status indicators (" BOARD OK "LED and" COMM OK "LED) and a handheld monitor connector for access to all devices mounted on the bus. The IC660CBB902 bus controller also has four upper terminals for serial bus connections and low connector jumpers (JP1, JP2, and JP3) for Genius I/O bus terminations.
