Technical specifications for IC660EBA020
Brand GE Fanuc
Series Genius I-O
Part number IC660EBA020
Describes the electronic components of the Genius I/O analog module
Application Genius I/O module system
Operating voltage 18 to 56 volts DC
Equipped with LED 2 status LED indicators
Enter four 12-bit inputs
Output two 12-bit outputs
Rated power 8.0 watts
Mounting terminal assembly
Input update 4 milliseconds
Input filter 1024 ms
GE Fanuc IC660EBA020 Genius I/O Analog Block Electronic Component Assembly is an electronic component assembly of GE IC66BBA020 voltage/current analog block. The IC66BBA020 I/O Block is a Phase B analog module electronic component assembly with 4 analog inputs and 2 analog outputs. The IC66BBA020 I/O module includes a compatible terminal Assembly, such as the IC66TSA020 terminal assembly, and an electronic assembly, such as the IC660EBA020 Electronics Assembly. The terminal assembly forms the basis of the module and provides connection points for bus cables, field devices, handheld monitors, and EEPROM modules. The IC660EBA020 Electronics Assembly houses the module's processor, which performs all of the module's functions, including data storage and communication.
The IC660EBA020 Electronics Assembly operates in a voltage range of 18 to 56 volts DC with a maximum power rating of 6.0 watts. The maximum accuracy value of the simulated I/O module is +/-0.5% full scale, with a maximum thermal drift of 40 ppm (parts per million) per degree Celsius. Standard circuit options for IC660EBA020 Electronics components are 0 to 10 volts DC, +/-10 volts DC, +/-5 volts DC, 0 to 5 volts DC, 0 to 20 and 4 to 20 MA (or 1 to 5 volts DC). The IC660EBA020 Electronics Assembly features four 12-bit analog inputs with input update times of 4 ms and optional input filter times of up to 1024 ms. The IC660EBA020 Electronics Assembly has two 12-bit outputs that can be configured to retain the last status value in the event of lost communication with the CPU. The IC660EBA020 Electronics assembly can be mounted on the terminal base by perfectly alecting the assembly to the guide rail and securing it with factory supplied set screws.
