Technical specifications for IC697PWR748
Brand GE Fanuc
Series 90-70 series
Part number IC697PWR748
Nominal rated voltage 48 volts DC
Input voltage range 35 to 60 VDC
Maximum input power 160 watts at full load
Input surge energy 60 VDC maximum 28 joules at input
Output power up to 90 watts (total power from all 3 outputs)
Minimum load +5 VDC 1.0A
Time travel minimum 10 milliseconds
VME support Yes
Overcurrent protection Yes
The maximum temperature is 50 degrees Celsius
The IC697PWR748 module is a rack-mounted power module designed, manufactured and distributed by GE Fanuc Automation. The module is designed to operate only at full capacity, which is 90 watts of total power. It can be inserted directly into the rack via a 48-pin backplane connector on the left side of the rack. The module can be used with one rack, and it is also capable of powering a second rack at the same time, but only if it is compatible with the module's specifications and does not exceed maximum power requirements. When the GE Fanuc Automation IC697PWR748 rack-mounted power module is used to power the second rack, the current consumed is less than 5.2 amps, and the second rack requires only 5 volts of power.
The GE Fanuc Automation IC697PWR748 rack-mounted power module comes with 3 outputs, each capable of operating at 5 volts DC and 18 amps, 12 volts DC and 1.5 amps, and -12 volts DC and 1 amp at output power and specific current. The module has a nominal line voltage of 48 volts DC and a supply voltage range of 35 to 60 volts DC. GE Fanuc Automation IC697PWR748 rack-mounted power modules provide electronic overcurrent limits for each of its outputs. If the maximum rated current is exceeded, the output voltage will drop. This is done to avoid further damage to the rack and power module from excessive current. In addition to inserting the module, the user also needs to secure it with mounting screws. These screws are supplied with the module.
