Technical specifications for IC697VAL134
Brand GE Fanuc
Series 90-70 series
Part number IC697VAL134
Type converter board
Converter analog-to-digital converter
Resolution 12 bits
Input channel 31
Input Type Single-ended analog input channel
Scan automatically. 40 kHz polymerization rate
Input range 50 mV to 10 VDC
Cable separation cable
Equipped with leds Yes, front panel
Isolation voltage 1000 volts DC
The IC697VAL134 board is a converter board designed and manufactured by GE Fanuc Automation. The board is specifically intended to be used as a signal converter device. It can scan analog input channels and convert signals from analog to digital. The specific converter embedded in the board is an ADC converter with a resolution of 12 bits. The board does not need to use any software after it is powered on, and it begins to scan each input channel. GE Fanuc Automation IC697VAL134 Converter boards have input ranges from +/- 50 microvolts to +/- 10 volts DC with input overvoltage protection. The board also has an isolation voltage of 1000 volts DC.
The GE Fanuc Automation IC697VAL134 converter board includes a front panel LED to indicate the status of the input. The board occupies 128 bytes of I/O VMEbus space and comes with jumpers that provide space for the board on any 128 byte boundary. Before installing the GE Fanuc Automation IC697VAL134 converter board, the equipment needs to be powered off to ensure the safety of the equipment and technicians during the installation process. The board is equipped with 40 Hz input filters, which have been configured in the factory. The Board is divided into different functional categories such as Board ID register, BIT voltage reference, and analog input multiplexing category. For some applications, the board needs to be calibrated to function properly. Frequent maintenance is also recommended to check the physical state of the board and its connections.
