MVI46-103M PROSOFT main communication module
The MVI46-103M(" IEC 60870-5-103 Master Communication Module ") allows Rockwell Automation SLC I/O compatible processors to easily interface with IEC 60870-5-103 slave (controlled unit) protection devices. Compatible devices include relays, circuit breakers, sub-station communication modules and other serial communication devices.
1.1 General Specifications
The MVI46-103M module interfaces with Rockwell Automation SLC processors for up to 32 serial communication devices.
Two communication port modules act as control devices (Masters) to interface with controlled devices on their own networks. Each port can be configured individually. Data is exchanged between the serial network and Rockwell Automation processors using an internal database contained in the module, with ladder logic controlled directly by the controller.
Some common specifications include:
Two independent master ports built according to internationally recognized specifications, fully configurable by the user up to 32 sessions (controlled devices) up to 5 sectors per session (separate database) (ii) A separate database for each sector defines 1000 commands for control stations The SLC processor can issue control commands directly to the module or module Control devices (ii) Delivery of event messages
